Wiseco Piston Kit with Gasket — 100.00 mm — Yamaha
- Complete piston kit includes pistons, rings, wrist pins, circlips and top-end gasket kit for one complete engine
- Wiseco ring types are not interchangeable (i.e., CD is not interchangeable with LC)
- Wiseco pistons can be fitted only with Wiseco rings
- Cylinder sleeves must be purchased separately.
$365.95
In stock. Ships in 2–4 business days · free shipping over $150.
View cart & check out →
Questions? Call the shop: 801-361-3010
Real shop · real humans · 1231 N 1300 W Ste A, Centerville, UT 84014
Shop all Wiseco
Everything we carry from Wiseco →
Everything we carry from Wiseco →
Description & features4 features
Kit Includes:
• Piston Kit #4966M10000
• Ring Set #3937XS
• Wrist Pin #S655
• Wrist Pin Retainer Set #CW22
• Gasket Kit #W6428
- Complete piston kit includes pistons, rings, wrist pins, circlips and top-end gasket kit for one complete engine
- Wiseco ring types are not interchangeable (i.e., CD is not interchangeable with LC)
- Wiseco pistons can be fitted only with Wiseco rings
- Cylinder sleeves must be purchased separately.
Specifications15 specs
- Compression Ratio
- 9.9:1
- Skirt Coating
- ArmorGlide®
- Units
- Kit
- Riding Style
- UTV, ATV
- Displacement
- 660 cc
- Piston Diameter
- 99.92 mm
- Stroke Length
- 84.00 mm
- Type
- Top End
- Engine Type
- 4-Stroke
- Piston Material
- 2618 Aluminum Alloy
- Model
- Forged Series
- Bore Size
- 100.00 mm
- Shipping weight
- 2.2 lb
- Package size
- 8.5 × 7.9 × 5.4 in
- Country of origin
- USA
Fitment8 models · Yamaha
Yamaha8 models
- YFM 660 FA Grizzly 4x42008
- YFM 660 FG Grizzly 4x42008
- YFM660F Grizzly 4x42002–2006
- YXR66F Rhino 6602005–2007
- YXR66F Rhino 660 Ducks Unlimited2007
- YXR66F Rhino 660 Exploring Edition2006–2007
- YXR66F Rhino 660 Special Edition2006–2007
- YXR66F Rhino 660 Sport Edition2007
Fitment comes from the catalog data for this part. Double-check your year, model and trim before you order — or call the counter at 801-361-3010 and we’ll check it with you.
Part numbers
- Salto part #
- 0903-0625
- Wiseco part #
- PK1435
Shipping
In stock. Ships in 2–4 business days by ground.
Ground shipping is $14.95, free on orders over $150. Stock is checked again before your card is charged.
Questions4 answers
- Is it in stock?
- Yes — it’s in stock right now. We check again the moment you order, before anything is charged.
- How fast will it get to me?
- Usually 2–4 business days by ground.
- Will it fit my machine?
- It’s listed for the models in the Fitment section above. Not sure about your trim or year? Call the counter at 801-361-3010 and we’ll check it with you.
- Is this genuine Wiseco?
- Yes. It’s new and genuine, straight from Salto — Wiseco part #PK1435.
