Athena Crankshaft — Vertical Engine — Scooter — Aprilla | MBK | Yamaha 50 · 50
- Made of special steel and manufactured with CNC high-precision machinery
- Standard stroke
$221.95
In stock. Ships in 2–4 business days · free shipping over $150.
View cart & check out →
Questions? Call the shop: 801-361-3010
Real shop · real humans · 1231 N 1300 W Ste A, Centerville, UT 84014
Shop all Athena
Everything we carry from Athena →
Everything we carry from Athena →
Description & features2 features
Big End Bearing: 20.00 mm x 26.00 mm x 13.80 mm
Big End Width: 14.00 mm
Pivot Fly Wheel Diameter: 20.00 mm
Pivot Pulley Diameter: 20.00 mm
Shoulder Width: 45.00 mm
Washer Thickness: 20.00 mm
Big End Bore: 20.00 mm
Center-to-Center: 95.95 mm
Piston Pin Diameter: 18.00 mm
Pivot Fly Wheel Length: 61.00 mm
Pivot Pulley Length: 52.50 mm
Small End Width: 14.00 mm
- Made of special steel and manufactured with CNC high-precision machinery
- Standard stroke
Specifications7 specs
- Units
- Each
- Displacement
- 50 cc
- Riding Style
- Street
- Stroke Length
- 39.20 mm
- Shipping weight
- 2.9 lb
- Package size
- 11.2 × 6.1 × 3.9 in
- Country of origin
- Italy
Fitment8 models · Aprilia, MBK, Yamaha
Aprilia1 models
- Amico 501996–1998
MBK1 models
- Stunt2000–2002
Yamaha6 models
- BW Next Generation 501997–2000, 2002–2005
- BW Next Generation Kat1999–2000
- BWs 502012
- Slider2000–2002
- Spy1997–1998
- Zuma 501998–2001
Fitment comes from the catalog data for this part. Double-check your year, model and trim before you order — or call the counter at 801-361-3010 and we’ll check it with you.
Part numbers
- Salto part #
- 0921-0019
- Athena part #
- S410130320004
- UPC
- 8050444897027
