In warehouse stock

Hot Rods Connecting Rod Kit — Yamaha

Hot Rods · #0923-0564 · Bottom End / Engine

Certified 8620 AISI steel provides superior strength
Uniquely designed big end uses strategically located side scalloping vent slots to minimize high-RPM bearing race distortion
Crankpins are manufactured from hot-rolled ASTM 4115 and case hardened to 58-62Rc
Hot Rods uses the latest in caged needle roller bearing designs for high RPM longevity
Thrust washers are manufactured from bronze phosphor and are silver coated

$159.95

In stock. Ships in 2–4 business days · free shipping over $150.

Questions? Call the shop: 801-361-3010

Real shop · real humans · 1231 N 1300 W Ste A, Centerville, UT 84014

Description & features8 features

Connecting Rod Big End I.D. 29.000 mm

Connecting Rod Big End Width: 17.000 mm

Connecting Rod Center-to-Center: 102.000 mm

Connecting Rod Small End I.D. 19.000 mm

Connecting Rod Small End Width: 16.000 mm

Thrust Washer Thickness: 1.000 mm

Pin Length: 54.500 mm

Kit Includes:

• Connecting Rod

• Crank Pin

• Crank Pin Bearing

• Wrist Pin Bearing

• Thrust Washers

Certified 8620 AISI steel provides superior strength
Uniquely designed big end uses strategically located side scalloping vent slots to minimize high-RPM bearing race distortion
Crankpins are manufactured from hot-rolled ASTM 4115 and case hardened to 58-62Rc
Hot Rods uses the latest in caged needle roller bearing designs for high RPM longevity
Thrust washers are manufactured from bronze phosphor and are silver coated
Rod assembly sold complete with rod, crankpin, crankpin bearing, top-end bearing and thrust washers
Compatible with Hot Rods and OE crankshafts
Made in USA

Specifications8 specs

Material: 8620 Steel
Riding Style: Off-Road
Engine Type: 2-Cycle
Units: Kit
Displacement: 125 cc
Shipping weight: 0.75 lb
Package size: 6.8 × 2.3 × 1.6 in
Country of origin: USA

Fitment2 models · Yamaha

Yamaha2 models

YZ1252005–2021
YZ125X2020–2022

Fitment comes from the distributor’s catalog. Double-check your year, model and trim before you order — or call the counter at 801-361-3010 and we’ll check it with you.

Part numbers

Salto part #: 0923-0564
Hot Rods part #: 8718

Shipping

In stock at a distributor warehouse. Ships in 2–4 business days by ground.

Ground shipping is $14.95, free on orders over $150. Stock is re-checked with the warehouse before your card is charged.

Questions4 answers

Is it in stock?: Yes — the distributor shows it on a shelf at a regional warehouse right now. We check again the moment you order, before anything is charged.
How fast will it get to me?: Usually 2–4 business days by ground.
Will it fit my machine?: The distributor lists it for the models in the Fitment section above. Not sure about your trim or year? Call the counter at 801-361-3010 and we’ll check it with you.
Is this genuine Hot Rods?: Yes. It ships new from the same distributors the big online stores buy from — Hot Rods part #8718.
