S&S Cycle Cam Chest Kit — Water Cooled — Gear Drive — 465 Cam — Black Pushrod Tubes — M8

S&S Cycle · #0925-1662 · Bottom End / Camshafts & Install Kits

Improves cam timing accuracy and eliminates the stock cam chain tensioner
All parts in each kit are matched to ensure superior quality, fit, finish and performance
Oil pump and cam plate are precision-machined from billet aluminum with a blue anodized finish
Passage plugs removable for servicing
Independent scavenge sections for the flywheel cavity and cam chest

$1924.95

In stock. Ships in 2–4 business days · free shipping over $150.

Can’t ship to California.

Questions? Call the shop: 801-361-3010

Real shop · real humans · 1231 N 1300 W Ste A, Centerville, UT 84014

Shop all S&S Cycle
Everything we carry from S&S Cycle →

Description & features17 features

Improves cam timing accuracy and eliminates the stock cam chain tensioner
All parts in each kit are matched to ensure superior quality, fit, finish and performance
Oil pump and cam plate are precision-machined from billet aluminum with a blue anodized finish
Passage plugs removable for servicing
Independent scavenge sections for the flywheel cavity and cam chest
Debris screens in both scavenge pickups
Increased oil flow capacity on both the feed and scavenge sides
Adjustable Pressure Relief Valve is adjustable with unit installed in engine
Magnet in cam chest to help to stop debris from entering oil pump
S&S Quickee Pushrods with finished pushrod tubes
S&S premium tappets
Billet aluminum tappet cuffs have a hard-anodized black coating and are stronger than stock to eliminate distortion
Improved tappet stability in high-lift and high-rpm situations
Provides improved cam timing accuracy and eliminates the stock cam chain tensioner
Made in the USA
Will fit M8 models with VVT.
Outer drive gears included.

Specifications21 specs

Exhaust Lift: 0.462"
Exhaust Lobe Centerline: 100.6° Front, 103.6° Rear
Intake Lift: 0.462"
Type: Gear Drive
Exhaust Open: 30.1° Front, 33.1° Rear
Features: Black Pushrod Tubes
Application: Water Cooled
Intake Lift at TDC: 0.087° Front, 0.088° Rear
Intake Lobe Centerline: 96.0° Front, 95.8° Rear
Exhaust Lift at TDC: 0.109° Front, 0.098° Rear
Grind: 465G
Riding Style: Street
Units: Kit
Exhaust Close: 8.8° Front, 5.8° Rear
Exhaust Duration: 218.9°
Intake Close: 14.6° Front, 14.4° Rear
Intake Duration: 197.2°
Intake Open: 2.6° Front, 2.8° Rear
Shipping weight: 12.45 lb
Package size: 16 × 11 × 4.6 in
Country of origin: USA

Fitment17 models · Harley-Davidson

Harley-Davidson17 models

FLHLT Street Glide 3 Limited2026
FLHLTSE CVO Street Glide 3 Limited2026
FLHTCU Electra Glide Ultra Classic2017–2019
FLHTCUTG Tri Glide Ultra2017–2025
FLHTCUTG Tri Glide Ultra G.I.2022
FLHTCUTGSE CVO Tri Glide2020–2022
FLHTK Ultra Limited2017–2024
FLHTKL Ultra Limited Low2017–2019
FLHTKSE CVO Limited2017–2021
FLHXL Street Glide Limited2026
FLHXLSE CVO Street Glide Limited2026
FLHXSTSE CVO Street Glide ST2026
FLTRXL Road Glide Limited2026
FLTRXRRSE CVO Road Glide RR2025
FLTRXSE CVO Road Glide2023–2025
FLTRXSTSE CVO Road Glide ST2024–2026
Tri Glide Ultra Classic FLHTCUTG2025

Fitment comes from the catalog data for this part. Double-check your year, model and trim before you order — or call the counter at 801-361-3010 and we’ll check it with you.

Part numbers

Salto part #: 0925-1662
S&S Cycle part #: 310-1009B

Shipping

In stock. Ships in 2–4 business days by ground.

Ground shipping is $14.95, free on orders over $150. Stock is checked again before your card is charged.

California: this part can’t ship to a California address.

Questions4 answers

Is it in stock?: Yes — it’s in stock right now. We check again the moment you order, before anything is charged.
How fast will it get to me?: Usually 2–4 business days by ground.
Will it fit my machine?: It’s listed for the models in the Fitment section above. Not sure about your trim or year? Call the counter at 801-361-3010 and we’ll check it with you.
Is this genuine S&S Cycle?: Yes. It’s new and genuine, straight from Salto — S&S Cycle part #310-1009B.
